LTECH SE-6-500-G1T 6.25W 500mA TRIAC/ELV Dimmable LED Driver

Constant Current Driver with Leading and Trailing Edge Dimming

The LTECH SE-6-500-G1T is a compact constant-current LED driver designed for smooth phase-cut dimming of low-power LED lighting. Providing a fixed 500mA output, it is well suited to residential, hospitality, retail and architectural applications where a small driver format is required. SE-6-500-G1T

Supporting both leading-edge TRIAC and trailing-edge ELV dimming, the driver offers broad compatibility with conventional phase-cut dimmers. Dimming is smooth from 0–100% down to 0.1%, while T-PWM technology provides flicker-free performance with soft-on and fade-in operation for comfortable low-level lighting control. SE-6-500-G1T

Operating from a 220–240V AC input, the SE-6-500-G1T provides a 500mA constant-current output across a 2–12.5V DC range, with a maximum output power of 6.25W. Its compact 84 × 20 × 20mm housing makes it particularly suitable for installations where space is limited. SE-6-500-G1T SE-6-500-G1T

Compact and easy to integrate, the SE-6-500-G1T features Class II construction and IP20 protection, together with overheat, over-voltage, overload and short-circuit protection with automatic recovery. A service life of up to 100,000 hours and a 5-year warranty support dependable professional LED lighting installations. SE-6-500-G1T
