BOKE BK-DRL010S-AHC0500ADN 10.5W DALI-2 Dimmable Constant Current LED Driver

Compact DALI-2, pushDIM and NFC-Programmable LED Driver for Professional Lighting

The BOKE BK-DRL010S-AHC0500ADN is a compact 10.5W constant-current LED driver designed for intelligent and energy-efficient indoor lighting applications. Featuring DALI-2 and pushDIM control, its circular housing makes it ideal for LED downlights, circular track lights and other compact luminaires used in residential, retail, hospitality and commercial environments.

Operating from a 200–240V AC/DC input, the driver provides a programmable output current from 100mA to 500mA and an output voltage range of 2.5–42V DC, subject to its 10.5W maximum output power. Output current can be configured using BOKE EasySet software through DALI or NFC programming. A typical power factor of 0.90 and efficiency of 84% support dependable operation.

The BK-DRL010S-AHC0500ADN supports DALI-2 DT6 and pushDIM dimming from 0.1–100%, delivering smooth, flicker-free brightness control. Advanced functionality includes EnergyData reporting, programmable Constant Light Output (CLO) and corridorDIM for automated lighting applications. The driver also supports central and self-contained emergency lighting systems.

Designed for built-in luminaire installation, the driver features Class II construction, SELV output and IP40 protection. Integrated short-circuit, overload, over-temperature and hot-plug protection help maintain reliable performance. With a nominal lifetime of up to 100,000 hours, CE, ENEC, UKCA and DALI-2 certifications, and a 5.5-year manufacturer guarantee, it offers a versatile solution for professional dimmable LED lighting systems.
