BOKE BK-DAL080-B2000Ad 80W DALI-2 Dimmable Constant Current LED Driver

Slimline DALI-2 and pushDIM LED Driver for Professional Linear Lighting

The BOKE BK-DAL080-B2000Ad is a slimline 80W constant-current LED driver designed for efficient and flexible indoor lighting applications. Featuring DALI-2 and pushDIM control, it is ideal for LED linear lights, tri-proof luminaires, bracket lights and other slimline fittings used in commercial, retail, office and industrial environments.

Operating from a 200–240V AC/DC input, the driver provides an adjustable constant-current output from 1250mA to 2000mA, selectable through a 16-level DIP switch. Its regulated output voltage ranges from 6–42V DC, depending on the selected current, with a maximum output power of 80W. A power factor of 0.96 and typical efficiency of 90% support dependable, energy-efficient operation.

The BK-DAL080-B2000Ad supports DALI-2 DT6 and pushDIM dimming, offering smooth, flicker-free brightness adjustment from 1–100%. Its amplitude modulation technology provides precise lighting control, while integrated short-circuit, overload, no-load and hot-plug protection help ensure reliable performance. The driver also supports central and self-contained emergency lighting applications.

Designed for built-in installation, the driver features Class I construction, SELV output and an IP20 rating for indoor use. With a nominal lifetime of up to 100,000 hours, CE, ENEC, UKCA and DALI-2 certifications, and a 5.5-year manufacturer guarantee, it offers a reliable solution for professional dimmable LED lighting systems.
