BOKE BK-CWL013 Series 12.6–14W Constant Current LED Drivers

Slimline Non-Dimmable LED Drivers for Professional Linear Lighting

The BOKE BK-CWL013 Series is a range of compact constant-current LED drivers designed for reliable and efficient indoor lighting applications. Available in fixed 300mA and 350mA output versions, the series is well suited to LED linear lights, tri-proof luminaires, bracket lights and other slimline fittings used in commercial, retail, office and industrial environments.

Operating from a 200–240V AC/DC input, the drivers provide a regulated 28–42V DC output range, depending on the selected model, with maximum output powers of 12.6W and 14W. Their dual-stage circuit design delivers stable, flicker-free illumination, while a high power factor of 0.96 and typical efficiency of 83.5% help ensure dependable lighting performance.

The BK-CWL013 Series is non-dimmable and supports both central and self-contained emergency lighting applications. Its slim linear housing allows straightforward integration into compatible luminaires, while integrated short-circuit and no-load protection help maintain reliable operation.

Designed for built-in installation, the drivers feature Class I construction, SELV output and an IP20 rating for indoor use. With a nominal lifetime of up to 100,000 hours, CE, ENEC and UKCA certifications, and a 5.5-year manufacturer guarantee, the BK-CWL013 Series provides a practical solution for professional constant-current LED lighting systems.
